Surveying the Faroe Islands

Local authorities in the Faroe Islands use drones to overcome challenging, changeable weather when surveying land use and mapping coasts. The maps these UAVs create can generate orthophotos requiring less effort and strain than aircraft-based photogrammetry, the Faroese Environment Agency found out.

With a global population of 7.8 billion, and 55% living in urban areas, the world is rapidly shifting from being mostly in rural areas to built-up cities. This is happening everywhere – from huge countries like China to the smallest of island nations, like the Faroe Islands.

The Faroe Islands, in the north-west Atlantic Ocean, have just roughly 53,000 inhabitants across 18 islands. There are 120 urban areas spread over these islands. Mapping and tracking urban development is key to helping record land use across the territories as well as changes to the nearby coastline that are frequent in island territories.

Towards an accurate Faroe Islands map

The Faroese Environment Agency, or Umhvørvisstovan, takes charge of mapping and tracking progress across the islands, including coastline mapping. These maps are used for land planning as well as for the national register. However, being in the middle of the Atlantic, aerial mapping of the islands is quite a challenge. Since 2017, Umhvørvisstovan has collected 117,130 images at a rate of roughly 30,000 per year. There are only six employees to carry out all the responsibilities of a governmental agency. Three work on land with surveying and mapping, whilst three others work on nautical charts for ships and ferries.

In 2015, Umhvørvisstovan decided to work with unmanned aerial vehicles (UAVs or 'drones') instead of aircraft. When they started using drones for mapping, they researched the strengths of drone photogrammetry. Part of the appeal is that the maps could generate orthophotos with less effort and strain than aircraft-based photogrammetry. As for selecting the right drone mapping software, with a large-scale project, the power ofPix4Dmaticturned out to be well suited for producing an accurate Faroe Islands map.

Why drone mapping was the best choice

Svínoy is a tiny island, with just 31 inhabitants. However, the last time the island was mapped was in 2009. It was long overdue for an up-to-date survey.

Several significant challenges are present with aerial mapping remote locations. The islands have mountainous terrain with strong winds. The Faroe Islands weather is notoriously unpredictable. Aircraft struggle to penetrate the cloud cover and the risks of flying beneath the clouds with such rough terrain mean it is very difficult to fly safely for aerial mapping.

The benefit of drones is already clear: they can be deployed with less notice and planning than an aircraft, and take advantage of short gaps in favourable weather. Furthermore, drones fly below the clouds which is an advantage in that their visibility is not prevented by cloud cover. Meanwhile, the continuous grey skies cause a consistent light that does not change dramatically, which is ideal for photogrammetry data collection. However, fixed-wing drones do sometimes struggle due to the uneven terrain making it hard to find appropriate locations to take off and land.

Land surveying a remote island

When the Environment Agency’s pilot flew, the data collection mission was separated into three flights that gathered a total of 1,997 images. This careful flight planning can save pilots lots of time whenflying large or complicated sites. Luckily, the wind was gentle that day. There was some turbulence and difficulty from the layout of the terrain, although luckily Svínoy has some flat spaces from which the eBee X could take off and land safely.

The data was then processed in Pix4Dmatic, taking just over ten hours to crunch the whole dataset. The final map was then edited and annotated to add important details, including coastlines, housing (including road names and addresses) and pastures and agricultural plots.

This map is provided as anopen-access resource for anyone to download(albeit in Danish). Open maps are a useful resource, enabling everyone to better understand the lay of the land.

Benefits of remote surveying

This transition to having up-to-date records is highly valuable to the government. Whilst it is free to download for the public, it gives an insight into the progress and development of the Faroe Islands, even on the smallest isles. The variety ofoutputs from Pix4Dmaticalso means Umhvørvisstovan can use them for mapping or planning further development.

“Pix4Dmatic is even easier to use than Pix4Dmapper and the processing time was faster. So if time is an important factor in your projects, you can speed up your delivery on large projects by using Pix4Dmatic,” said Andreas Arnbjerg, pilot for Umhvørvisstovan.

By working with drones and photogrammetry, Umhvørvisstovan can save the costs of using airplanes to gather data, as well as be more flexible according to the weather as they do not need to use a more labor-intensive flight. UAVs cut hours spent in the field and the processing power of Pix4Dmatic renders incredibly detailed results that both authorities and community members benefit from.
